SL90-23 TRANSAXLE
Designed primarily for two-wheel-drive rally-raid, the SL9O-23 is designed for driving across dunes, steppes and the trickiest terrain. Thanks to its ingenious design, it absorbs heavy loads from V8-type engines and sudden increases in torque administered by the most difficult circuits.
TECHNICAL SPECS
- 6 speed sequential gearbox + 1 reverse gear
- Super-polished bevel gear ratio 9×34 or 8×35
- The bevel gear is cut and grinded in house on our CNC units
- Wide range of ratios available
- Straight cut gears
- Dog ring gear engagement
- Interchangeable gear ratios
- High strength carburizing steel
- Gear teeth grinded with optimized profile
- Shot penning on internal parts
- Specific input shaft
- Hydraulic clutch bearing
- Central limited slip differential
- Ramp and plate system – 3 discs type
- Preload made by belleville spring washer
- Wide range of ramp plates available
- Reverse lockout cable or option of solenoïd
- Splash lubrication system
- Oil pump integrated
- Directed and pressurised lubrication on the gears and bevel gear
- Oil suction screen
- Magnetic drain plugs
- Painted AS7G aluminum casings
- Assembled with spacers and studs
- Weight (input shaft included) : 85 kg – 187 lbs
